iPhone 14 Pro Max
- 16/09/2022
-
240 g (8.47 oz)
-
iOS 16, upgradable to iOS 17.5.1, planned upgrade to iOS 18
-
128GB 6GB RAM, 256GB 6GB RAM, 512GB 6GB RAM, 1TB 6GB RAM
6.7 inches, 110.2 cm2 (~88.3% screen-to-body ratio)
12 MP, f/1.9, 23mm (wide), 1/3.6", PDAF, OIS
128GB 6GB RAM, 256GB 6GB RAM, 512GB 6GB RAM, 1TB 6GB RAM
Li-Ion 4323 mAh, non-removable (16.68 Wh)
Network
Technology
GSM / CDMA / HSPA / EVDO / LTE / 5G
Launch
Released Date
16/09/2022
Status
Available
Body
Dimensions
160.7 x 77.6 x 7.9 mm (6.33 x 3.06 x 0.31 in)
Weight
240 g (8.47 oz)
Build
Glass front (Corning-made glass), glass back (Corning-made glass), stainless steel frame
SIM
Nano-SIM and eSIM – International
Dual eSIM with multiple numbers – USA
Dual SIM (Nano-SIM, dual stand-by) – China
IP68 dust/water resistant (up to 6m for 30 min)
Apple Pay (Visa, MasterCard, AMEX certified)
Display
Type
Li-Ion 4323 mAh, non-removable (16.68 Wh)
Size
6.7 inches, 110.2 cm2 (~88.3% screen-to-body ratio)
Resolution
1290 x 2796 pixels, 19.5:9 ratio (~460 ppi density)Ceramic Shield glass
Protection
Ceramic Shield glass
Platform
OS
iOS 16, upgradable to iOS 17.5.1, planned upgrade to iOS 18
Chipset
Apple A16 Bionic (4 nm)
CPU
Hexa-core (2×3.46 GHz Everest + 4×2.02 GHz Sawtooth)
GPU
Apple GPU (5-core graphics)
Memory
Card slot
No
Internal
128GB 6GB RAM, 256GB 6GB RAM, 512GB 6GB RAM, 1TB 6GB RAM
Main Camera
Dual
48 MP, f/1.8, 24mm (wide), 1/1.28″, 1.22µm, dual pixel PDAF, sensor-shift OIS
12 MP, f/2.8, 77mm (telephoto), 1/3.5″, 1.0µm, PDAF, OIS, 3x optical zoom
12 MP, f/2.2, 13mm, 120˚ (ultrawide), 1/2.55″, 1.4µm, dual pixel PDAF
TOF 3D LiDAR scanner (depth)
Features
HDR, Cinematic mode (4K@24/30fps)
Video
Selfie camera
Single
12 MP, f/1.9, 23mm (wide), 1/3.6", PDAF, OIS
Sound
Loudspeaker
Yes, with stereo speakers
3.5mm jack
12 MP, f/1.9, 23mm (wide), 1/3.6", PDAF, OIS
Comms
WLAN
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, hotspot
Bluetooth
5.3, A2DP, LE
Positioning
GPS (L1+L5), GLONASS, GALILEO, BDS, QZSS
NFC
Yes
Radio
No
USB
Lightning, USB 2.0
Features
Sensors
Face ID, accelerometer, gyro, proximity, compass, barometer
Ultra Wideband (UWB) support
Emergency SOS via satellite (SMS sending/receiving)
Battery
Type
Li-Ion 4323 mAh, non-removable (16.68 Wh)
Charging
Wired, PD2.0, 50% in 30 min (advertised)
15W wireless (MagSafe)
15W wireless (Qi2) – requires iOS 17.2 update
Misc
Colors
Space Black, Silver, Gold, Deep Purple
Models
A2894, A2651, A2893, A2895, iphone15,3
SAR
1.15 W/kg (head) 1.07 W/kg (body)
SAR EU
0.99 W/kg (head) 0.98 W/kg (body)
Tests
Performance
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, hotspot
Display
5.3, A2DP, LE
